Description
5-inch to 32-inch size range, Customization is welcome!
Touch: No touch or 5 Wires Resistive Touch or 10 Points Capacitive Touch Optional.
What Differences Between Capacitive Touch and Resistive Touch?
Features:
● 1. 350nits for indoor application.
● 2. Three Buttons for control: red, green, yellow, and One Button for Emergency Stop.
● 3. Dust-proof, FULL IP65 waterproof, and shock-proof.
● 4. DC 12V power supply (DC24V, 9-36V Optional), support power-on boot, 7x24hours.
● 5. Fanless aluminum alloy shell, sturdy and durable with an efficient heat dissipation system.
Highlights:
1. FULL IP65 waterproof;
2. Buttons for control: red, green, yellow, and One Button for Emergency Stop:
Red/Green/Yellow from Left to Right Description:
1-2Pin: 5V LED + –
3Pin: C IN Line
4Pin: NO Line
5Pin: NC Line
Emergency Stop: AC 100-240V
1Pin: C IN Line
2Pin: NO Line
3Pin: NC Line
Size Optional:
| 7″ / 8″ | 10.1″ | 12.1″ | 13.3″ | 15″ l 15.6″ | 17″ | 19″ | 21.5″ |
| 1024*600 1024*768 | 1280*800 1024*768 | 1280*800 | 1920*1080 | 1024*768 /1920*1080 | 1280*1024 | 1280*1024 | 1920*1080 |
| 4:3 | 16:10 | 16:10 | 16:9 | 4:3 l 16:9 | 4:3 | 4:3 | 16:9 |
Applications:
Transportation – Marine, Air, Heavy Vehicles, Weigh Stations, Fleet Management, Telematics, In-Car Computing, Public Transit, Cargo
System Integration – Machinery Controls, Factory Automation, Environmental Monitoring, Home Automation, Military, Smart Home
Point of Sale – Hospitality, Digital Signage, Self-Service Kiosks, Outdoor Kiosks and Signage, Casino, Sea Food Industry; SlaughterHouse; BreadHouse; Car Washing System
Data Monitoring – Cloud, IoT, Medical, Logistics, Inventory Management, Oil & Gas/Utilities, Law Enforcement, Broadcasting, Veterinary, First Person View
Broadcast & Production – Broadcast Stations, Mobile Production Vehicles, Field Rugged Deployment for your mobile workforce, Studio Video Production
