Description
Do you want to extend the service life of your monitor or panel pc?
If there is a case: you have a black monitor or panel pc with FULL IP67 Waterproof. You might not be able to repair it by yourself, but it’s such a waste to throw it away.
Now, no worries. Our engineer designed a new model with easy uninstallation & installation way without industrial glue fixing the enclosure.
1) You can replace the screen easily, and repair it.
2) Thus, it can extend the service life of your screen. That means, buying 1 product is equivalent to 2-3 times the use time. It helps you to save money, and trouble is easily solved, too.
5-inch to 32-inch size range, Customization is welcome!
Touch Optional: No Touch or 5 Wires Resistive Touch or 10 Points Capacitive Touch.
What Differences Between Capacitive Touch and Resistive Touch?
Features:
● 1. NEMA4/IP67 waterproof and dustproof design, all interfaces with CNLINKO connectors
● 2. SUS304 stainless steel enclosure, more resistant to corrosion, shock, and vibration
● 3. Adopting EETI solution + industrial-grade capacitive touch, high performance
● 4. DC 12V power supply (DC24V, 9-36V Optional), support power-on boot, 7x24hours
● 5. Screen replaceable design for repair, easy uninstallation & installation to extend the service life:
1) Screw Fixing design, easy uninstallation & installation for screen replacement or repair.
2) A gasket, and rubber ring sealed the junction, no industrial glue for FULL IP67 waterproof.
Highlights:
1. FULL IP67 waterproof, Stainless Steel Enclosure for anti-corrosion;
2. Anti-glare glass, reduce the shadow under the screen;
3. High brightness 1000nits~1500nits, sunlight-readable;
What Is A Nit Of Screen Brightness And How Many Do You Need?
4. Industrial grade, wide temperature: -30℃/-20℃ to +70℃/+80℃;
5. Optical bonding for moisture condensation prevention.
How to Choose SCREEN for Outdoor or Semi-outdoor Application?
Size Optional:
| 7″ 8″ | 10.1″ 10.4″ | 12.1″ | 13.3″ | 15″ 15.6″ | 17″ 17.3″ 18.5″ | 19″ 19″ wide | 21.5″ 23.8″ 24“ |
| 1024*600 1024*768 | 1280*800 1024*768 | 1024*768 1280*800 | 1920*1080 | 1024*768 1920*1080 | 1280*1024 1920*1080 | 1280*1024 1440*900 | 1920*1080 |
| 16:9 4:3 | 16:10 4:3 | 4:3 16:10 | 16:9 | 4:3 16:9 | 4:3 16:9 | 4:3 16:10 | 16:9 |
CPU Optional:
| RK3399 Dual Cortex-A72+Quad Cortex-A53, 2.0GHz, fanless | ||
| RK3568 Quad Core 64-bit Cortex-A55, ARM, 2.0GHz, fanless | ||
| Intel® Celeron J1900, quad core, 2.0GHz, fanless | ||
| Intel® Core I3-4005U, dual core, 1.7Ghz, fanless | ||
| Intel® Core I3-5005U, dual core, 2.0Ghz, fanless | ||
| Intel® Core I3-7100U, dual core, 2.3Ghz, fanless | ||
| Intel® Core I5-4200U, dual core, 1.6Ghz, fanless | ||
| Intel® Core I5-5200U, dual core, 2.2Ghz, fanless | ||
| Intel® Core I5-6200U, dual core, 2.3Ghz, fanless | ||
| Intel® Core I5-7200U, dual core, 2.5Ghz, fanless | ||
| Intel® Core I7-4500U, dual core, 1.8Ghz, fanless | ||
| Intel® Core I7-6500U, dual core, 2.5Ghz, fanless | ||
| Intel® Core I7-7500U, dual core, 2.7Ghz, fanless |
