Description
5-inch to 32-inch size range, Customization is welcome!
Touch Optional: No Touch or 5 Wires Resistive Touch or 10 Points Capacitive Touch.
What Differences Between Capacitive Touch and Resistive Touch?
Features:
● 1. Front bezel IP65 waterproof and dustproof design
● 2. Aluminum alloy enclosure, more resistant to corrosion, shock and vibration
● 3. Adopting EETI solution + industrial-grade capacitive touch, high performance
● 4. DC 12V power supply (DC24V, 9-36V Optional), support power-on boot, 7x24hours
● 5. High brightness 1000nits for outdoor application, 400nits Optional for indoor
Highlight:
High brightness, 1000nits, sunlight-readable.
What Is A Nit Of Screen Brightness And How Many Do You Need?
Specifications:
Size Optional:
| 7″ 8″ | 10.1″ 10.4″ | 12.1″ | 13.3″ | 15″ 15.6″ | 17″ 17.3″ 18.5″ | 19″ 19″ wide | 21.5″ 23.8″ 24″ |
| 1024*600 1024*768 | 1280*800 1024*768 | 1024*768 1280*800 | 1920*1080 | 1024*768 1920*1080 | 1280*1024 1920*1080 | 1280*1024 1440*900 | 1920*1080 |
| 16:9 4:3 | 16:10 4:3 | 4:3 16:10 | 16:9 | 4:3 16:9 | 4:3 16:9 | 4:3 16:10 | 16:9 |
CPU Optional:
| Intel® Celeron J1900, quad core, 2.0GHz, fanless | ||
| Intel® Core I3-4005U, dual core, 1.7Ghz, fanless | ||
| Intel® Core I3-5005U, dual core, 2.0Ghz, fanless | ||
| Intel® Core I3-7100U, dual core, 2.3Ghz, fanless | ||
| Intel® Core I5-4200U, dual core, 1.6Ghz, fanless | ||
| Intel® Core I5-5200U, dual core, 2.2Ghz, fanless | ||
| Intel® Core I5-6200U, dual core, 2.3Ghz, fanless | ||
| Intel® Core I5-7200U, dual core, 2.5Ghz, fanless | ||
| Intel® Core I7-4500U, dual core, 1.8Ghz, fanless | ||
| Intel® Core I7-6500U, dual core, 2.5Ghz, fanless | ||
| Intel® Core I7-7500U, dual core, 2.7Ghz, fanless |
| Mainboard | CPU | J1900, i3, i5, i7 | ||
| RAM | 2GB/4GB/8G | |||
| SSD | 32GB/64GB/128GB/256GB | |||
| Screen | Panel size | 8″ | ||
| Resolution | 1024*768 4:3 | |||
| Brightness | 1000nits (cd/m²) (400nits Optional) | |||
| Touchscreen | 5 Wires Resistive Touch | |||
| 10 Points Capacitive Touch Optional | ||||
| Surface Treatment | Anti-glare Glass (Optional) | |||
| Optical Bonding (Optional) | ||||
| Dimming | Auto-dimming with light sensor (Optional) | |||
| Contrast ratio | 800:1(Typ.) | |||
| View Angle | 80°/80°/80°/80°(R/L/U/D) | |||
| Surface Hardness | ≥2H | |||
| Working Life | ≥50 million times | |||
| Power Supply | Working voltage | DC12V (DC24V, 9-36V Optional) | ||
| Environment | Temperature | Operating: -20°C to 70°C, storage: -20°C to 70°C | ||
| Relative humidity | 10%~90% @ 30° C, non-condensing | |||
| Enclosure | Material | Aluminum Alloy | ||
| Color | Black | |||
| VESA mounting | 75x75mm | |||
| IP grade | Front IP65 waterproof | |||
| Dimension | Net weight | / | ||
| Gross weight | / | |||
| Product size | 218*175*44mm | |||
| Packing size | / | |||
| I/O Interfaces | 1xHDMI, 4xUSB, 2xLAN, 6xCOM, 1xAudio, 1xDC, 1xON/OFF | |||
| WIFI/RS485/Speaker Optional | ||||
| 1xVGA Optional | ||||
| Accessories | 1x12V 5A Adaptor, 1x Power Plug, 1xWall Mounting Bracket | |||
| OS | Support Windows 7/8/10, WES, Linux, Ubuntu, Debian, etc. | |||
| Mountings | Embedded mounting screws | |||
| Wall mounting brackets; Desk stand holder (optional) | ||||
| Warranty | 1-year free warranty | |||
